Free Revit 2023 Project: Four-Storey Braced Steel Frame Structural Model (Abgar Ivanyan)

Overview

Abgar Ivanyan (MEng Civil Engineering, Imperial College London) shares Revit structural models of a four-storey braced steel office frame originally designed as coursework. The building is 24.5 x 32.5 m on plan and 22 m tall, in S355 steel, with a central transfer truss at first floor carrying the internal columns.

The project rebuilds the frame in Revit with an analytical representation for export to Oasys GSA and comparison against Eurocode 3 checks; the README marks it as in progress, and so far the repository holds three Revit models and a baseline member register. The files were saved in Revit 2023 and are free to download.
