Free Fusion 360 CNC Milling Set: Drawing, Model, G-code (eduvision)

Original title: CNC Fräsen Video 16 RN+ RN- / Fusion360 + Technische Zeichnung A3 + Palmill Datei

Free Fusion 360 CNC Milling Set: Drawing, Model, G-code (eduvision)
Preview from the original source by Technische Bildung (eduvision)

What you get: Project

Visit Original Project

Access: Free (email signup)

Gumroad: if a price box appears, type 0 to get it for free.

Overview

This teaching set from Technische Bildung (eduvision) accompanies video 16 of its German CNC milling series, which deals with RN+ and RN- corner compensation. It bundles three files that trace a drawing-to-machining chain for one part: an A3 technical drawing, the Fusion 360 model file, and the Palmill G-code for milling it, so you can follow how a drawn part becomes a toolpath.

The set is available on Gumroad as a pay-what-you-want download starting at €0 after entering an email address; the extension of the Fusion 360 source file is not stated. Useful for vocational students and hobby machinists comparing the CAD model, drawing and G-code for the same part.

What You Can Learn

  • Drawing-to-machining chain: A3 drawing, Fusion 360 model and Palmill G-code for one part
  • RN+/RN- corner compensation in a CNC milling exercise (video 16)

Comments

Loading comments…
