Free Revit 2021 Dynamo Script Pack: Energy Model, Daylight Zone and TRACE 700 Graphs (Ripcord Engineering)

Overview

Jake Staub of Ripcord Engineering shares Dynamo graphs that automate MEP engineering tasks in Autodesk Revit on GitHub. The AutomatedBuildingEnergyModel series creates walls, floors, roofs and conceptual masses from space volume geometry, AutomatedDaylightModel builds daylight zones as masses for 3D DWG export to Velux Daylight Visualizer, and a TRACE700 graph writes room checksum data from a CSV file into matching space parameters.

Workflow PDFs for gbXML and Speckle, demo gbXML and DWG files and two helper Python scripts are included, and the README marks each graph as tested in Revit 2021 with Dynamo 2.3. The GPL-3.0 files are a free download from GitHub.
