Free Revit 2022 Dynamo Script Pack: Parametric Modeling and Computational Geometry Graphs (The BIM Coordinator)

Overview

The BIM Coordinator (GitHub user DaltonGOO) followed ParametricCamp's Intro to Parametric Modeling series in Dynamo instead of Grasshopper and shares the resulting graphs on GitHub. The folder includes facade triangulation and random panels, Pratt, Vierendeel and Warren trusses, a free-form roof with circular lanterns, parametric solar panels, a landscape with random vegetation and a park furniture layout with its family and model.

A second folder explores computational geometry, such as Delaunay and Voronoi tables, point in polygon, closest pair of points and the shortest path problem. The README names TestingModel_Revit2022.rvt as the model all graphs run on, some graphs use packages such as LunchBox, and everything is a free download from GitHub.
