Free Revit Dynamo Script Pack: MEP Airflow, Spaces and Insulation Graphs (BIMUpYourLife)

Overview

BIMUpYourLife shares 19 Dynamo graphs for Revit MEP work in the DynamoUpYourLife repository on GitHub. They cover air terminal flow, room airflow, pipe insulation sizing, SIA room calculation export and import, MEP space creation, diffuser data exchange with Excel, toggles for maintenance and mounting spaces, and openings.

Eight custom nodes (.dyf) and three sample models (RME.rvt, MEP-Spaces.rvt, Levelnames.rvt) are included, and the graphs are saved in the older Dynamo 1.x format, some with German names. The files are a free direct download from GitHub under a CC BY-NC-SA 4.0 licence.
