Free Revit Dynamo Script Pack: Navisworks Clash Bubbles and Builderswork Openings (Sunny Mak)

Overview

Sunny Mak shares Dynamo for Revit graphs from daily MEP coordination work on GitHub. The Clash Bubble graphs read a Navisworks XML clash report and place clash ball families that carry the clash data through shared parameters, with the families for Revit 2019 and 2021 and the clash report template.

The Builderswork set creates, merges and deletes BWIC opening families where services cross structure and makes section views of them, with the opening family, a shared parameter sheet and test models. A further graph numbers elements in the order of a model curve, and the MIT-licensed files are a free download from GitHub.
