Free Revit Dynamo Script Pack: Pipe Sleeves, Duct Dampers and Conduit Checks (Slava Krel)

Overview

Slava I Krel keeps a small set of Revit Dynamo graphs for MEP coordination on GitHub. They insert pipe sleeves automatically, place damper families where ducts cross walls, report conduit length and bend count, check whether conduit parameters are filled out, select all elements in a conduit run and export element solids to OBJ.

A 3D gridline graph comes with a 3-D grid family and a custom node for renaming grids. The files are a free direct download from GitHub.
